Technical Notes
- Motor power: 250W
- Standard voltage: 220V
- Speed: Can be adjusted
- Control: Remote control
- Track width: 37mm
- Packing: Wooden case (especially for export)
Technical Data
| Platform Height (m) | Max. Lifting Capacity (kg) | Platform size (cm) | Dead weight (kg) | Tray Material | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2.5 | 30 | 40*60*30 | 64 | 304 stainless | |||||||||||||||
| 3 | 30 | 40*60*30 | 67 | 304 stainless | |||||||||||||||
| 3.5 | 30 | 40*60*30 | 70 | 304 stainless | |||||||||||||||
| 4 | 30 | 40*60*30 | 73 | 304 stainless | |||||||||||||||
| 4.5 | 30 | 40*60*30 | 76 | 304 stainless | |||||||||||||||
| 5 | 30 | 40*60*30 | 79 | 304 stainless | |||||||||||||||
| 5.5 | 30 | 40*60*30 | 82 | 304 stainless | |||||||||||||||
| 6 | 30 | 40*60*30 | 87 | 304 stainless | |||||||||||||||
| 7 | 30 | 40*60*30 | 92 | 304 stainless | |||||||||||||||
| 8 | 30 | 40*60*30 | 97 | 304 stainless |
