Curve Edge Banding Machine with Swing Arm Advantage for Furniture and Cabinet Making
- Auxiliary Automatic Feeding – The auxiliary feeding system frees your hands and makes edge banding easier on circular, oval, and rounded rectangular panels.
- Laser Precision Jointing – Equipped with a laser alignment system, the machine detects the starting point of the edge banding strip and automatically cuts it, ensuring seamless and accurate joints.
- Efficient Corner Processing – When the photoelectric switch detects a corner, the profiling wheel automatically reduces speed; when detecting a straight edge, it accelerates again. This ensures smooth edge finishing while maintaining high efficiency.
- Advanced Gluing Assembly – The integrated glue pot and coating assembly deliver consistent, even adhesive application for strong, long-lasting edge bonding.
- Automatic Trimming & Scraping – Features upper and lower flush trimming, following scraper for smooth edges, and thickness self-adjustment without manual calibration, ensuring perfect results on different panels.
Main Configurations of Curve MDF Edge Bander Machine Automatic
- Dual-Purpose Top Glue Pot (PUR/EVA) – Flexible glue application system supporting both PUR and EVA adhesives for strong and durable bonding.
- Auxiliary Automatic Feeding System – Assists in feeding curved panels such as circular, oval, and rounded rectangular shapes, reducing manual effort.
- Laser Precision Jointing – Laser sensor detects the start of the edge banding strip and automatically cuts for seamless and accurate joints.
- Rotatable Edge Banding & Trimming Heads – Machine heads can rotate to adapt to different panel angles and shapes, ensuring precise processing.
- Automatic Speed Adjustment at Corners – When the photoelectric switch detects corners, the profiling wheel slows down; when detecting straight edges, it accelerates again for both efficiency and quality.
Curve PVC Edge Banding Machine Wood Door Edge Bander Machine Specifications
| Power supply voltage | AC110V/220V/240V/380V/400V, 1P/3P, 50HZ/60HZ |
|---|---|
| Total power | 6.5kw |
| Air source pressure | 0.6-0.8Mpa |
| Glue pot capacity | 2600ml |
| Glue pot temperature | 110℃-210℃ |
| Hot melt adhesive type | PUR/EVA |
| Edge banding width | 14-70mm |
| Edge banding thickness | 0.5-3mm (depending on the edge banding material) |
| Trimming plate thickness | <14mm single-side trimming, 14-70mm upper and lower double trimming (related to trimming knife) |
| Inner arc radius | ≥20mm(Special operation can seal radius 4mm) |
| Edge banding speed | 0-30cm/ |
| Profiling speed | 0-24cm/s |
| Gas tank capacity | 2L |
| Head rotation angle | 15° |
| External vacuum cleaner | Ф150mm |
| Air volume | 9800m³/h |
| Edge banding types | PVC, veneer (need to be customized), plastic, melamine, etc. |
| Packing size | 187×140×153cm |
| Weight | 530kg |
